M6
Diameter - M6
Pitch - 1.00
Width (flat to flat hex) - 10mm
Height (Hex part only) - 4mm
Overall height (include round top) - 6mm
M8
Diameter - M8
Pitch - 1.25
Width (flat to flat hex) - 13mm
Height (Hex part only) - 5.5mm
Overall height (include round top) - 8mm
M10
Diameter - M10
Pitch - 1.5
Width (flat to flat hex) - 17mm
Height (Hex part only) - 6.5mm
Overall height (include round top) - 10mm
M12
Diameter - M12
Pitch - 1.75
Width (flat to flat hex) - 19mm
Height (Hex part only) - 8mm
Overall height (include round top) - 12mm
